| Cisco Catalyst 2960X-48TS-LL Specifications | | |
| model info: | WS-2960X-48TS-LL | |
| enclosure type | Rack-mountable - 1U | |
| Ports | 48 x 10/100/1000 + 2 x 1G SFP Ports | |
| Network management Interface | 10/100 Mbps Ethernet (RJ-45) | |
| Available PoE Power | None PoE | |
| Forwarding bandwidth(Gbps) | 50Gbps | |
| Maximum stacking number | None | |
| Stack Bandwidth | None | |
| Forwarding Performance | 104.2Mpps | |
| Switching bandwidth | 100Gbps | |
| Maximum active VLANs | 64 | |
| MAC Address Table Size | 16K (default) | |
| CPU | APM86392 600MHz dual core | |
| RAM | 256 MB | |
| Flash Memory | 64 MB | |
| Status Indicators | Per-port status: Link integrity, disabled, activity, speed, and full duplex System status: System, RPS, Stack link status, link duplex, PoE, and link speed |
| Expansion / Connectivity | | |
| Console ports | USB (Type-B), Ethernet (RJ-45) | |
| Stacking cable | None | |
| Power Redundancy | Option (PWR-RPS2300) | |
| Voltage range (Auto) | 110V-240V | |
| Power Consumption Operational | 0.46KVA | |
| Miscellaneous | | |
| Width | 17.5 Inches (44.5 Cm) | |
| Depth | 11 Inches (27.9 Cm) | |
| Height | 1.75 Inches (4.5 Cm) | |
| Weight | 8.9 Pounds (4.0Kg) | |
| Rack Mounting Kit | optional | |
| MTBF in hours | 476,560 | |
| Compliant Standards | ● IEEE 802.1D Spanning Tree Protocol
● IEEE 802.1p CoS Prioritization
● IEEE 802.1Q VLAN
● IEEE 802.1s
● IEEE 802.1w
● IEEE 802.1X
● IEEE 802.1ab (LLDP)
● IEEE 802.3ad
● IEEE 802.3af and IEEE 802.3at
● IEEE 802.3ah (100BASE-X single/multimode fiber only)
● IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports | ● IEEE 802.3 10BASE-T
● IEEE 802.3u 100BASE-TX
● IEEE 802.3ab 1000BASE-T
● IEEE 802.3z 1000BASE-X
● RMON I and II standards
● SNMP v1, v2c, and v3
● IEEE 802.3az
● IEEE 802.1ax |
| System software / license | | |
| System software | IOS LAN Lite | |
| license | NERGY-MGT-100-K9, EW-DO-100-DE | |
| features | ● Jumbo Frames ● VLANS ●Voice Vlan●VTPv2 ●CDPv2 ●LLDP ● 802.3ad LACP ● PVST/PVST+ ● 802.1W/802.1S●Port Fast/Uplink Fast ● port CoS Trust and Override ● Scheduling ● Priority Queuing ● Configure CoS Priority Queues ● Weighted Tail Drop ● DSCP transparency | |
| Network security | ● SSH, SSL and SCP ● RADIUS and TACACS+ ● SNMPv3 crypto ● 802.1x ● 802.1x Accounting / MIB ● 802.1x w/ port security ● 802.1x w/Voice VLAN ● 802.1x Guest VLAN ● 802.1x VLAN assignment ● 802.1x MAC-Auth Bypass ● BPDU/Root Guard ● Port Security ● Private VALN Edge ● Storm Control ● Block unknown unicast and multicast ● IGMP Snooping ● IGMP Filter/Throttle | |
| Management and Troubleshooting | ●Auto-MDOX ●TDR ● UDLD ● IP SLA Responder ● layer 2 / IP Traceroute ● SPAN ● RSPAN ● Express Setup ● Device Manager ● Cisco Network Assistant ● Smartports + Advisor ● Troubleshooting Advisor ● Drag-and-drop Cisco IOS Upgrade ● IP Address DHCP ● Autoinstall with saved configuration ● Configuration Replace ● DHCP Auto Image Upgrade ● DHCP Port Based Allocation ● Error Disable MIB | |
| Environmental Ranges | | |
| Fahrenheit | Centigrade |
| Operating temperature up to 5000 ft (1500 m) | 23ºF to 113º | -5ºC to 45ºC |
| Operating temperature up to 10,000 ft (3000 m) | 23ºF to 104ºF | -5ºC to 40ºC |
| Short-term exception at sea level* | 23ºF to 131ºF | -5ºC to 55ºC |
| Short-term exception up to 5000 feet (1500 m)* | 23ºF to 122ºF | -5ºC to 50ºC |
| Short-term exception up to 10,000 feet (3000 m)* | 23ºF to 113ºF | -5ºC to 45ºC |
| Short-term exception up to 13,000 feet (4000 m)* | 23º to 104ºF | -5ºC to 40ºC |
| Storage temperature up to 15,000 feet (4573 m) | -13º to 158ºF | -25º to 70ºC |
| Feet | Meters |
| Operating altitude | Up to 10,000 | Up to 3000 |
| Storage altitude | Up to 13,000 | Up to 4000 |
| Operating relative humidity | 10% to 95% noncondensing | |
| Storage relative humidity | 10% to 95% noncondensing | |
Pay attention that it takes WS-C2960X-48TS-L for reference. These two switches' back panels are similar but WS-C2960X-48TS-LL has not FlexStack-Plus module slot.
